BEC-100B/4P 電涌保護器SPD
閱讀次數(shù)：3848 發(fā)布時間：2023-05-25
| 所屬類別 | 型號名稱 | 主要參數(shù)說明 | ||||||
| 保護模式 | Uc(V) | Imax(kA) | In(kA) | Up(kV) | Iimp(kA) | 實驗類別 | ||
| 第1級（低風險）產(chǎn)品型號目錄 | ||||||||
| 電源 | BEC-20D/1P | L-PE | 275 | 20 | 10 | 1.2 | / | T2 |
| BEC-20D/2P | L-PE、N-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-20D/3P | L-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-20D/4P | L-PE、N-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-40C/1P | L-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-40C/2P | L-PE、N-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-40C/3P | L-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-40C/4P | L-PE、N-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-60B/1P | L-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-60B/2P | L-PE、N-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-60B/3P | L-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-60B/4P | L-PE、N-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-RMON-20D/1P | L-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-RMON-20D/2P | L-PE、N-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-RMON-20D/3P | L-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-RMON-20D/4P | L-PE、N-PE | 275 | 20 | 10 | 1.2 | / | T2 | |
| BEC-RMON-40C/1P | L-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-RMON-40C/2P | L-PE、N-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-RMON-40C/3P | L-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-RMON-40C/4P | L-PE、N-PE | 320 | 40 | 20 | 1.5 | / | T2 | |
| BEC-RMON-60B/1P | L-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-RMON-60B/2P | L-PE、N-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-RMON-60B/3P | L-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-RMON-60B/4P | L-PE、N-PE | 385 | 60 | 40 | 2.1 | / | T2 | |
| BEC-80B/4P | L-PE、N-PE | 385 | 80 | 50 | 2.5 | / | T2 | |
| BEC-RMON-80B/4P | L-PE、N-PE | 385 | 80 | 50 | 2.5 | / | T2 | |
| BEC-120B/1P | / | 385 | 120 | 80 | 2.5 | / | T2 | |
| BEC-100B | / | 385 | / | 20 | 2 | 20 | T1 | |
| 信號 | BEC-V485 | 線-地/X-C | 18V AC | / | / | 0.5 | / | C2:10kV/5kA |
| BECRJ45-100B | 線-地/X-C | 8V DC | / | / | 0.7 | / | C2:5kV/2.5kA | |
